Product Summary

The N80C19816 is a kind of CHMOS microcontroller. Intel s CHMOS process provides a high performance along with low power dissipation. To further reduce power requirements, the processor can be placed into Idle or Powerdown Mode. With the commercial (standard) temperature option, operational characteristics are guaranteed over the temperature range of 0 to +70℃. With the extended temperature range option, operational characteristics are guaranteed over the temperature range of -40 to +85℃.

Parametrics

Ratings: (1)with the commercial (standard) temperature option, operational characteristics are guaranteed over the temperature range of 0 to +70℃; (2)With the extended temperature range option, operational characteristics are guaranteed over the temperature range of -40 to +85℃; (3)high performance along with low power dissipation; (4)1.75μs 16×16 multiply (16 MHz); (5)3.0μs 32/16 Divide (16 MHz).

Features

Features: (1)8 Kbytes of on-chip ROM available; (2)232 byte register file; (3)register-to-register architecture; (4)28 interrupt sources/16 vectors; (5)1.75μs 16×16 multiply (16 MHz); (6)3.0μs 32/16 Divide (16 MHz); (7)powerdown and Idle modes; (8)16-bit watchdog timer; (9)8-bit external bus; (10)full duplex serial port; (11)high speed I/O subsystem; (12)16-bit timer; (13)16-bit counter; (14)pulse-width-modulated output; (15)four 16-bit software timers; (16)10-bit A/D converter with sample/hold; (17)extended temperature available.

Diagrams
