MAX517ACSA

2-Wire Serial, 8-Bit DACs, Rail-to-Rail Outputs, SOP, Single +5V Supply, 4μA Power-Down Mode

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.00

PartNumber:: MAX517ACSA

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. shanna wei's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-08

From Other Seller

Part Number:MAX517ACSA
US $1.00 - 1.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX517ACSA is a 8-bit voltage output digital-to-analog converter (DAC) with a simple 2-wire serial interface that allows communication between multiple devices. They operate from a single 5V supply and their internal precision buffers allow the DAC outputs to swing rail-to-rail. The MAX517ACSA is a single DAC and the MAX518/MAX519 are dual DACs. The MAX518 uses the supply voltage as the reference for both DACs. The MAX517ACSA has a reference input for its single DAC and each of the MAX519 two DACs has its own reference input. The MAX517ACSA features a serial interface and internal software protocol, allowing communication at data rates up to 400kbps. The interface, combined with the double-buffered input configuration, allows the DAC registers of the dual devices to be updated individually or simultaneously. In addition, the devices can be put into a low-power shutdown mode that reduces supply current to 4μA. Power-on reset ensures the DAC outputs are at 0V when power is initially applied. The MAX517ACSA is available in space-saving 8-pin DIP and SO packages.

Parametrics

MAX517ACSA absolute maximum ratings: (1)VDD to GND: -0.3V to +6V; (2)OUT_: -0.3V to (VDD + 0.3V); (3)REF_ (MAX517, MAX519): -0.3V to (VDD + 0.3V); (4)AD_: -0.3V to (VDD + 0.3V); (5)SCL, SDA to GND: -0.3V to +6V; (6)Maximum Current into Any Pin: 50mA; (7)Operating Temperature Ranges: 0℃ to +70℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temperature (soldering, 10sec):+300℃.

Features

MAX517ACSA features: (1)Single +5V Supply; (2)Simple 2-Wire Serial Interface; (3)I2C Compatible; (4)Output Buffer Amplifiers Swing Rail-to-Rail; (5)Space-Saving 8-pin DIP/SO Packages (MAX517/MAX518); (6)Reference Input Range Includes Both Supply Rails(MAX517/MAX519); (7)Power-On Reset Clears All Latches; (8)4μA Power-Down Mode.
